mini stereo amplifier 10

Mini Stereo Amplifier

Mini stereo amplifier is smaller and lighter than professional audio amplifier. With its low-noise design, it produces high-quality, crystal-clear audio with minimal distortion and maximum power output.

Differing from the professional audio amplifier, Layvikay small amplifier has two types of speaker outputs: one is the constant resistance with 4-16Ω, and the other is the constant voltage with 70 V/100 V.

Without a doubt, they are your perfect choice for public broadcasting/ background music in shops, offices, schools, warehouses, churches, restaurants and other public areas.

  • Digital Display
  • SD Card/USB Audio Input
  • MIC+2 Independent Zones
  • Power and Clip LED Indicator
  • AC 110 V or 220 V Power Input
  • Constant Voltage + Constant Resistance Dual Functions

Small Amplifier for Home and Commercial

mini stereo amplifier 11

Specification

  • Model:ST-50E
  • Max Output Power 50 W
  • Freq. Resp.: 80 Hz-15 kHz ± 3 dB THD 0.05% @ 1kHz, 10% Rated Power
  • S/N Ratio: >85 dB
  • MIC Input unbalanced: 10 K -45 dB
  • LINE Input unbalanced: 10 K -10 dB
  • 100 V Impedance: >400
  • Equalizer Low: +/-12 dB @ 80 Hz; High +/-12 dB @16 KHz
  • AC Power Supply: AC 110 V / 220 V / 50-60 Hz
  • Working Temperature: -10℃~40℃
  • Storage Temperature: -30℃ ~85℃
  • Model:ST-80E
  • Max Output Power 80W
  • Freq. Resp.: 80 Hz-15 kHz ± 3 dB THD 0.05% @ 1kHz, 10% Rated Power
  • S/N Ratio: >85 dB
  • MIC Input unbalanced: 10 K -45 dB
  • LINE Input unbalanced: 10 K -10 dB
  • 100 V Impedance: >400
  • Equalizer Low: +/-12 dB @ 80 Hz; High +/-12 dB @16 KHz
  • AC Power Supply: AC 110 V / 220 V / 50-60 Hz
  • Working Temperature: -10℃~40℃
  • Storage Temperature: -30℃ ~85℃

Customized&Thoughtful Service

Most of parameters can be customized:

  • Your Logo and Package Design
  • The Front and Back Panel Design
  • Inner Circuit Design
  • Special Additional Function

Layvikay not only provides professional audio solution with latest technology, but also guarantees fast lead time and thoughtful service to ensure customers are sufficiently benefited from our high performance products at competitive pricing.
Contact our sales team and tell us your requirement,we are very pleased to recommend the most suitable mini stereo amplifier for you.

mini amplifiers
mini stereo amplifier 12
color box of mini amplifier

Package of Mini Stereo Amplifiers

  • Product Size:27.5x20x6.5cm
  • Product Inch Size:10.8”x7.9”x2.6”
  • Inner Color Box Size:32×25.5x11cm
  • Inch Size:12.6”x10”x4.3”
  • N.W:2.25kg/pc;4.95lb/pc
  • G.W:2.4kg/box;5.28lb/box
  • Outer Packing:8pcs/outer carton
